24W US/EU/UK/AU

Product Specifications
No-load power consumption
0.1W.
Protection
With Over-current, over-voltage, short-circuit, over-temperature protection to protect circuit.
Operating Temperature and Relative Humidity
0℃ to +40℃、 10%RH to 90%RH、
Storage Temperature and Relative Humidity、
-25℃ to +70℃、5%RH to 95%RH non-condensing
Drop Test
.
1M for wall mount type and 0.76M for desktop as above described. Test times for each 1 times, a total of 6 times； The horizontal surface consists of hardwood at least 13mm thick,the plug can be bend, and scratch, but the structure should not be damaged, and can work normally.
Insulation Resistance
100MΩ Min. between primary to secondary add 500Vdc test voltage.
Efficiency
Measured at 115Vac or 230Vac input voltage, Average efficiency can reach energy star VI (86.20%) standard.
Hi-Pot Test
.
Primary to Secondary: 3000Vac /10mA Max / 60S (when safety testing);
Primary to Secondary: 3300Vac /5mA Max / 3S (when production).
Leakage Current
0.25mA maximum, at nominal AC input voltage and frequency.
Lightning surge
.
EMS Standards；
SURGE LEVEL: ±1KV(DM), ±2KV(CM) Standards IEC61000-4-5.
Note：Power supply is not damaged, allowing restart.
Burn-In Test
2 hours at 40°C maximum, Normal input voltage, rated load.
MTBF：
When the power supply is operating within the limits of this specification the MTBF shall be at least 50000 hours at 25℃ (MIL-HDBK-217F).
